300W Explosion Proof LED Flood Light 36000lm IP67 Copper-Free Aluminum Salt Spray Resistant
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | Fins board, BOCAQ |
| Certification: | CE,ROHS,FCC,PSE,CCC,ATEX, ISO9001,BSCI |
| Model Number: | EPFL-300W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pcs |
|---|---|
| Packaging Details: | Box package+ bubble or as customized |
| Delivery Time: | 10-15 days or confirm |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 5000pcs/month |
|
Detail Information |
|||
| Power: | 300W | Luminous Flux: | 36000lm |
|---|---|---|---|
| Efficacy: | 120lm/W | Color Temperature: | 4000K (Neutral White) |
| Beam Angle: | 90° | Input Voltage: | AC 100-277V 50/60Hz |
| LED Chip: | Lumileds 3030 | CRI: | ≥70 |
| Power Factor: | ≥0.95 | IP Rating: | IP67 |
| IK Rating: | IK09 | Housing Material: | Copper-Free Aluminum Alloy With Marine-Grade Epoxy Coating |
| Lens Material: | Tempered Glass 5mm | Operating Temperature: | -40°C To +55°C |
| Highlight: | 300W IECEx Explosion Proof,Marine Offshore LED Floodlight,Copper-Free Aluminum Lighting |
||
Product Description
The EPFL-300W-MO is a purpose-built 300W explosion proof LED flood light engineered specifically for marine and offshore environments requiring IECEx certification. Featuring a copper-free aluminum alloy housing with marine-grade epoxy coating and IP67 submersion protection, this 36000lm floodlight withstands the most aggressive salt spray and corrosive atmospheres found in offshore oil & gas, shipyards, and coastal industrial facilities.
- 300W High Power Output - 36000lm luminous flux with 120lm/W efficacy, replacing 1000W HPS/HID fixtures
- IECEx Certified - IECEx Ex d IIC T6 Gb / Ex tb IIIC T85°C Db for Zone 1 and Zone 2 hazardous areas
- Copper-Free Aluminum Housing - Marine-grade A356 aluminum alloy eliminates galvanic corrosion risk, coated with C5-M epoxy for ISO 12944 marine durability
- IP67 Submersion Protection - Fully sealed against temporary immersion, ideal for wave-swept decks and wash-down zones
- Lumileds 3030 LEDs - Industry-leading LED chips providing 4000K neutral white light with excellent color rendering
- 90° Focused Beam Angle - Optimized for targeted illumination of work zones, helidecks, and process areas on offshore installations
- IK09 Impact Rated - Superior mechanical protection against accidental impacts in busy industrial environments
- Universal Voltage Input - AC 100-277V 50/60Hz compatible with vessel and platform power distribution systems
- Versatile Mounting - Adjustable bracket, wall mount, and ceiling mount options for flexible installation on FPSOs, jack-ups, and semi-submersibles
- 5-Year Warranty - Supported by ≥50,000 hours L70 rated lifespan and rigorous factory testing
Engineered for IECEx Zone 1 and Zone 2 classified offshore and marine locations:
- Offshore oil and gas production platforms
- FPSO (Floating Production Storage and Offloading) vessels
- Drilling rigs and jack-up platforms
- LNG carrier and tanker deck lighting
- Shipyard construction and repair docks
- Coastal petrochemical terminals and jetties
- Port and harbor hazardous cargo handling areas
- Subsea equipment maintenance workshops
| Model Number | EPFL-300W-MO |
|---|---|
| Power Consumption | 300W |
| Luminous Flux | 36000lm |
| Efficacy | 120lm/W |
| Color Temperature | 4000K (Neutral White) |
| Beam Angle | 90° |
| Input Voltage | AC 100-277V 50/60Hz |
| LED Chip | Lumileds 3030 |
| CRI | ≥70 |
| Power Factor | ≥0.95 |
| IP Rating | IP67 |
| IK Rating | IK09 |
| Housing Material | Copper-Free Aluminum Alloy A356 with C5-M Epoxy Coating |
| Lens | Tempered Glass 5mm |
| Salt Spray Resistance | C5-M Marine Grade (ISO 12944) |
| Operating Temperature | -40°C to +55°C |
| Mounting | Adjustable Bracket / Wall Mount / Ceiling Mount |
| Certification | IECEx Ex d IIC T6 Gb / Ex tb IIIC T85°C Db |
| Lifespan | ≥50,000 Hours L70 |
| Warranty | 5 Years |
Unlike standard industrial floodlights, the EPFL-300W-MO is built from the ground up for marine duty. The copper-free A356 aluminum alloy housing eliminates the bimetallic corrosion risk common in salt-laden atmospheres, while the C5-M epoxy coating system provides long-term protection per ISO 12944-2 standards. Every unit passes a 1000-hour salt spray test (ASTM B117) before shipment, ensuring decades of reliable service in the world's most demanding offshore environments.
For product specifications, volume pricing, or technical support, please reach out to our marine lighting specialists.
