>> Description
The explosion-proof platform light adopts a scientific sealing structure, with special sealing strips and embedding methods, and has excellent waterproof and dust proof performance. There are a variety of installation methods such as ceiling type, pole hanging type, bracket type, wall type, flange type, and guardrail type, with beautiful design and convenient operation.
>>Product structure performance
1. The casing is made of high-quality aluminum alloy die-casting, with high strength; the surface is treated with high-voltage electrostatic powder spraying, which is corrosion-resistant.
2. Branded LED light source is selected, with high luminous efficiency, high color rendering, small luminous space, low energy consumption, no flickering, long service life, maintenance-free, and no subsequent use costs.
3. Scientific light distribution design, high luminous efficiency, high utilization rate and large illuminated area. 380° all-round lighting, uniform lighting; soft light, no glare, effectively avoiding the visual fatigue of the staff.
4. The cavity of the light source is designed as an independent cavity, and the heat dissipation of the lamp is good, which prolongs the service life of the light source.
5. Integrated design, convenient for on-site installation and maintenance. It also simplifies wiring in the field.
6. Light source components, reflector components, power modules, etc. are all designed with standard modules, which are convenient to replace and reduce maintenance costs.
7. Scientific sealing structure design, special sealing strip and embedding method. With good waterproof and dustproof performance, it can be used in harsh environments.
8. The appearance is beautiful, the operation is simple and convenient, and there are ceiling-mounted and ceiling-mounted installations.
>>Scope of application
Explosion-proof platform lights are suitable for flood lighting requirements in railways, electric power, metallurgy, petroleum and petrochemical industries, various factories, workshops, stations, large facilities, venues and other places. No glare, no ghosting, impact resistance, corrosion resistance, energy saving, safety and reliability.
|
Product Model
|
SMSF50-C
|
|
Explosion Proof Sign
|
Exde IICT6 Gb
|
|
Power
|
AC220V50Hz
|
|
Rated Power
|
30-60W
|
|
Protection Level
|
IP65
|
|
Corrosion Protection Level
|
WF2
|
|
Inlet Thread
|
G3/4"
|
|
Incoming Cable
|
φ7-12mm
|
|
Working Temperature
|
Temperature: -40~45 ℃
Humidity: 10% -90%
|
|
Power Factor
|
≥0.95
|
|
Overall Dimensions
|
φ200*230
|
|
Net Weight
|
1.41kg
|
|
Color Temperature
|
2700-6500K
|
|
Color Rendering Index
|
80Ra
|
|
Luminous Flux
|
3900-7800lm
|
|
Working Life
|
≥50000H
|
>>Order notice
1. When ordering, please choose one by one according to the product model.
2. This lamp has been equipped with power supply and light source when it leaves the factory.
3. The lamps can be equipped with different installation methods.
4. The rated voltage of the lamp is AC220/50Hz, please use it at the rated voltage. 5. The standard color temperature of the lamp is 5500k~6500k.
6. If it is necessary for the 3, 4, and 5 items of the lamps to leave the factory, it should be stated when ordering.
