Product structure performance
◆Aluminum alloy die-casting shell with high-voltage electrostatic spraying on the surface;
◆Exposed stainless steel fasteners, high anti-corrosion performance;
◆High borosilicate physically toughened glass transparent cover, atomized anti-glare design, 4J high-energy impact resistance, and thermal fusion resistance. Light transmittance up to 90%;
◆Explosion-proof port form, the explosion-proof performance is more reliable;
◆Professional designed light distribution system with high light efficiency, high utilization rate, reasonable light distribution and uniform illumination;
◆Split structure of light source cavity, power supply cavity and wiring cavity, adopts indirect introduction method, and the wiring cavity is independent;
◆Professional internal protection structure design to ensure normal operation under harsh conditions;
◆Special constant current constant voltage power supply, wide voltage input. Constant power output. With constant current, open circuit protection, short circuit protection and other functions;
◆High power factor, cos>0.98;
◆Emergency devices can be equipped as needed. When the power is cut off, the lamps will automatically switch to the emergency lighting state;
◆Steel pipe wiring.
Explosion proof led light application
●Applicable to zone 1 and zone 2 of dry and explosive gas environment;
◆Suitable for zone 21 and zone 22 of combustible dust environment;
Applicable to llA, llB, llC explosive gas atmosphere;
◆Suitable for environments with temperature levels of T1~T6;
◆Widely used in hazardous environments such as oil exploration, oil refining, chemical industry, electric power, military industry and explosive gas environments on offshore oil platforms.
Customized service
Our company's explosion-proof lights can customize hardware accessories to provide customized support for different installation methods and places.
Product parameters
Product Number |
RF85 |
||
Explosion-Proof Mark |
Exde IICT6 Gb |
||
Rated Power |
50-70W |
80-120W |
120-180W |
Degree Of Protection |
IP65 |
||
Anti-Corrosion Grade |
WF2 |
||
Inlet Thread |
G3/4" |
||
Incoming Cable |
φ7-12mm |
||
Working Environment |
Temperature: -40~45℃ Humidity: 10%-90% |
||
Power Factor |
≥0.95 |
||
Dimensions |
φ240*290 |
φ280*300 |
φ320*400 |
Net Weight |
5kg |
6.59kg |
7.7kg |
Color Temperature |
2700-6500K |
||
Color Rendering Index |
80Ra |
||
Luminous Flux |
6500-23400lm |
||
Life Span |
≥50000H |
