6500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel

6500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel

Product Details:

Place of Origin: Chinese Mainland
Brand Name: Finboard
Certification: CE,ROHS,FCC,PSE,CCC,ATEX, ISO9001,BSCI
Model Number: RFEPL97

Payment & Shipping Terms:

Minimum Order Quantity: 10 pcs
Price: Negotiable
Packaging Details: Box package+ bubble or as customized
Delivery Time: 10-15 days or confirm
Payment Terms: T/T, Western Union
Supply Ability: 5000pcs/month
Get Best Price Contact Now

Detail Information
Keywords: Led Explosion Proof Light Power Factor: ≥0.95
Incoming Cable: φ7-12mm Protection Level: IP65/IP66
Color Temperature: 2700-6500K Color Rendering Index: 80Ra
Corrosion Protection Level: WF2 Application: Ming \tunnel \gas Station
Highlight:

6500lm Explosion Proof Lighting Fixtures

,

31200lm Explosion Proof Lighting Fixtures

,

6500lm explosion proof light fittings

Product Description

Led Mine Explosion Proof Light IP65 2700k To 6500k



Product description

LED tunnel explosion-proof lights provide a safe and reliable lighting solution for hazardous environments. Using efficient LED technology, the LED tunnel explosion-proof lights provide bright and reliable lighting for places such as underground mines. They are usually constructed of strong and durable materials such as aluminum or stainless steel to withstand harsh environmental conditions and often have a high level of safety certification for use in explosive environments.



Features

The product is made up of several key components that work together to deliver high performance results. The structure of the explosion-proof lamp consists of an aluminum alloy die-casting shell, which is then painted with high-voltage electrostatic spraying for added durability. The fasteners used on the product are made of stainless steel, which is highly resistant to corrosion.

The LED explosion tunnel light adopts high borosilicate physical tempered glass transparent cover, and adopts fogging anti-glare design, which increases safety and comfort. It is capable of withstanding high-energy shocks of up to 4J, making it highly resistant to thermal fusion. The light transmittance of the cover is as high as 90%, providing bright and clear illumination.




It has the form of casing flameproof and thread flameproof, which improves its explosion-proof performance and reliability. It has a professionally designed light distribution system that ensures high light efficiency and uniform illumination. The internal protective structure is also professionally designed to ensure the normal operation of the product under harsh conditions.

It has a special constant current and constant voltage power supply with wide voltage input and constant power output. It also has functions such as constant current, open circuit protection and short circuit protection. Its high power factor, cos>0.98, ensures maximum energy efficiency.

Explosion proof lights can be equipped with emergency devices upon request. When the power is cut off, the indicator light will automatically switch to the emergency lighting state. The wiring system of this product is also made of steel pipe, which ensures a safe and reliable connection.






Product Model

RFEPL97

Explosion Proof Sign

Exde IICT6 Gb

Rated Power

50-70W

80-150W

150-240W

Protection Level

IP66

Corrosion Protection Level

WF2

Inlet Thread

G3/4"

Incoming Cable

φ7-12mm

Work Environment

Temperature: -40~45 ℃
Humidity: 10% -90%

Power Factor

≥0.95

Overall Dimensions

250*170*150

320*225*220

460*310*230

Net Weight

3.35kg

6kg

11.5kg

Color Temperature

2700-6500K

Color Rendering Index

80Ra

Luminous Flux

6500-31200lm

Working Life

≥50000H



6500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 06500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 16500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 26500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 36500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 4

6500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 5

6500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 66500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 7

6500lm-31200lm Explosion Proof Lighting Fixtures Fittings For Tunnel 8
